Case Report - (2018) Volume 3, Issue 2
Background: Primary pulmonary malignant melanoma (PMM) is an extremely rare disease entity. There are limited published data on primary pulmonary malignant melanomas. The clinical manifestations and imaging features are non-specific. The imaging features of pulmonary melanoma have been described in previous reports, but it is still challenging to diagnosis it radiologically.
Case presentation: A 66 years old male presented with productive cough and back pain. His chest computed tomography (CT) scan revealed homogenous mass with higher density in left hilum with metastatic nodules in lungs. The metastatic lesions in vertebra on magnetic resonance imaging (MRI) were hyper-intense on T1WI and hypointense on T2WI. Further evaluation and immunohistochemical examination confirmed the diagnosis of primary pulmonary malignant melanoma with metastasis to vertebral bodies, liver, adrenal and lungs. He received 2 cycles of chemotherapy and died one month after initial diagnosis of the disease.
Conclusion: We have described pulmonary melanoma as bilateral homogenous nodules and mass with a higher computed tomography value. Although CT value has not been described in all literatures, many cases displayed higher density masses. So, clinicians should consider primary lung melanoma as a differential diagnosis for patients with such higher density mass in CT scan and hyper-intensity on T1WI and hypo-intensity on T2WI on MRI.
Keywords: Primary malignant melanoma; Lung; imaging manifestations
Melanoma, a malignant neoplasm of melanocytes, is one of the most aggressive cancers. Although malignant melanoma mainly occurs on the skin, it occurs in other mucosal sites and organs, including the oral cavity, paranasal sinuses, larynx, esophagus, liver, vagina, and anorectal region [1]. Worldwide, approximately 160,000 new cases of melanoma are diagnosed each year. Approximately 5-10% of patients with metastatic melanoma have a primary melanoma of unknown origin [1-3]. Commonly malignant melanoma of the respiratory system is metastatic in origin. Primary malignant melanoma of the lung is an extremely rare non-epithelial neoplasm with poor prognosis that accounts for only 0.01% of all primary lung tumors and only few cases have been reported [2,4]. Extra-pulmonary origin of the tumor including occult primary tumors must be excluded by the proposed clinical and pathological criteria before considering this diagnosis [3,5].
A 66-years-old man with medical history of hypertension for 8 years and stroke for 2 years and smoking history of 100 pack years since 13-63 years of age presented with complaints of productive cough and back pain for 1 month. The patient was suspected to have chest infection and empirically given antibiotic therapy in other hospital. The patient did not improve, and then he was referred to our hospital for further investigation and treatment.
His initial laboratory values were within the reference ranges. His chest X-ray showed bilateral nodules and mass lesions. The chest computed tomography without contrast (Figures 1a-1c) revealed bilateral multiple nodules and masses (mean CT value of 67 HU) and bilateral minimal pleural effusion. A large irregular heterogeneous mass measuring 6.9 × 6.5 cm was seen in the left hilum causing narrowing of the left lower bronchus. The other irregular solid mass measuring 4.3 × 3.6 cm was seen in the right lower lung lobe. Multiple nodules were noted around the pericardium. In the bone window, osteolytic destruction were seen on right fifth back ribs and multiple thoracic vertebral. The upper abdominal CT displayed multiple nodules in liver, spleen and bilateral adrenals (Figure 1d) (mean CT value of 52 HU) and multiple enlarged mesenteric and retroperitoneal lymph nodes (mean CT value of nodules is 57 HU).
Figure 1: Computed tomography showing (a) multiple nodules and mass in bilateral lung lobe in lung window, (b) the homogenous mass in mediastinal window near hilum (mean CT value 76 HU) and near pleura (mean CT value of 76 HU), (c) right lower lung lobe mass (mean CT value of 65 HU), (d) left adrenal gland (mean CT value of 52 HU).
The subsequent metastatic workup of brain and spinal nonenhanced magnetic resonance imaging (MRI) (Figure 2) showed multiple nodules in parietal bone (Figure 2c) and vertebral bodies (Figure 2a-2d) and multiple cervical lymphadenopathy. The lesions were hypo-intense on T1WI and hyper-intense on T2WI. The whole body bone scintigraphy showed increased metabolic activity of left clavicle, bilateral scapula, multiple ribs, 10th thoracic vertebrae and right ischial bone.
Figure 2: Magnetic resonance imaging showing metastatic lesion with (a) hyper-intensity on T1WI in thoracic vertebras, (b) hypo-intensity on T2WI in thoracic vertebra, (c) hyper-intensity on T1WI in skull, (d) hyper-intensity on T1WI in lumbar vertebras.
A percutaneous transthoracic needle biopsy was performed, and the histology showed melanoma cells with melanin pigments. Immunohistochemically (Figure 3), tumor cells were positive for human melanoma black 45(HMB-45), S-100 protein, Melan-A and VIMENTIN, while pancytokeratin (CK), CK5, CK6, thyroid transcription factor (TTF)-1, were negative. According to these pathologic findings, the tumor was diagnosed as malignant melanoma of the lung. Thorough dermatologic and other organ, including the eyes, gastrointestinal tract, and oral and nasal cavities examination, which can be primary sites of melanoma, didn't show evidence of melanoma. The patient was explained about the disease and its prognosis and chemotherapy was advised. He received 2 cycles of chemotherapy. Later he refused further treatment. He died after one month of initial diagnosis of the disease.
Figure 3: Immunohistochemistry of right lower pulmonary nodule showed that the tumor cells were CK (-), CK5/6 (-), HMB45 (+), Melan-A (+), S-100 (+), TTF-1 (-), and VIMENTIN (+).
General literature review
A literature search on PubMed and Medline database was performed using the key words 'pulmonary melanoma' or 'lung melanoma' and 'malignant melanoma', and yielded a total of 42 articles. Case reports in English language were included, and articles without CT imaging details were excluded. A total of 25 articles with reference information (Table 1) on 28 patients were used for the literature review and this analysis. Of 28 patients, 17 were male and 11 were female; the median age was 62 years (range, 13-89 years). The past medical history of PMM cases showed no inherited tendency and included tuberculosis, hypertension, diabetes mellitus, other malignancies such as basal cell carcinoma, prostate carcinoma, and cervical carcinoma. 21 patients had no significant past medical history. Smoking did not appear to be a risk factor, since only 6 of the 28 patients had a history of smoking.
| Author, year of publication, reference | No. of reported patients | Clinical manifestations | Primary imaging features in CT | Treatment | Outcome |
|---|---|---|---|---|---|
| Alghanem et al. [6] | 1 | Asymptomatic | A heterogeneous lobulated 6 cm mass in posterior segment of LLL | Lobectomy | Alive 2.5 years postop |
| Dountsis et al. [7] | 1 | Cough | A well-defined mass in RUL | Pneumonectomy + adjuvant therapy | Alive 18 mths postop |
| Ülger Al et al. [4] | 1 | Cough, dyspnoea, sputum production, weight loss | Multiple heterogeneous mass in RLL with pleural thickening and subcarinal LN enlargement | None | Died 1 mth after discharge |
| Reddy et al. [8] | 1 | Weight loss | A lobulated homogenous 3 × 8 cm mass with high denstity in LLL | Lobectomy | Alive 8 mths postop |
| Maeda at al. [9] | 1 | Asymptomatic | A homogeneous, illdefined, lobulated 4 × 3 cm masswith pleural thickening and subcarinal LN enlargement | Lobectomy | Died 6 mths postop |
| Seitelman et al. [10] | 1 | Asymptomatic | 4.5 cm mass in LLL | Lobectomy | Alive 5 yrs postop |
| Lazarou et al. [11] | 1 | Weakness, Upper GIT symptoms | A heterogeneous lobulated 5 × 9 cm mass with high density in RLL with mediastinal LN enlargement | Pneumonectomy | Died 13 mths after diagnosis |
| Neri et al. [12] | 2 | Asymptomatic | A round high density homogenous 2 × 3 cm mass in LLL | Lobectomy + Adjuvant chemotherapy | Died 6 mths postop |
| Bloody sputum | A round uniform high density homogenous 4 × 3 cm mass in RUL with mediastinal LN enlargement | Lobectomy + Adjuvant chemotherapy | Died 6 mths postop | ||
| Zuckermann et al. [13] | 1 | Asymptomatic | A well-defined 5 cm mass in RUL | Lobectomy + Adjuvant chemotherapy | Alive 6 yrs postop |
| Gong et al. [5] | 2 | Persistent cough | Multiple ill-defined mass in LUL, LLL | Chemotherapy | Died 4 mths after diagnosis |
| Dyspnoea, weakness | A round high density homogenous 6 × 4 cm mass in RLL | Lobectomy + Adjuvant chemotherapy | Alive 1.5 yrs postop | ||
| Ouarssani et al. [14] | 1 | Cough, sputum production, dyspnoea, chest pain, hemoptysis, weight loss | Well defined homogeneous mildly enhanced 6 cm mass in LLL and 2 cm mass in RLL with pleural effusion and mediastinal LN enlargement | Chemotherapy | Died 2 mths after diagnosis |
| Lares dos Santos et al. [15] | 1 | Dyspnoea, chest pain | An irregular homogeneous 3.5 cm mass in LUL with collapse of LUL | Chemoradiotherapy | Alive 12 mths after diagnosis |
| Kamaleshwaran et al. [16] | 1 | Neck pain | Multiple ill defined homogeneous mass 3 cm, 2 ccm in LLL | Pneumonectomy + Chemoradiotherapy | Alive 1 yr after diagnosis |
| Gupta et al. [17] | 1 | Chest pain, dry cough, fever, anorexia, weight loss | A large 8 × 9 cm heterogeneously enhancing mass in the LUL with central non-enhancing necrotic areas and pleural effusion | None | Died 2 mths after diagnosis |
| Filippini et al. [18] | 1 | Persisient cough, fever, dyspnoea | Mixed ground-glass and lobar consolidation in RUL, and ground glass with crazy paving appearance in RLL with multiple bilateral nodules | Chemo-immunotherapy | Died 3 mths after diagnosis |
| Hwang et al. [19] | 1 | Asymptomatic | A heterogeneous enhancing 8 cm mass with an inner low attenuating portion in RLL with pleural effusion | None | Died 3 mths after diagnosis |
| Mahowald et al. [20] | 1 | Cough | A homogenous 7.5 cm mass in LUL with pleural thickening | Pneumonectomy | Alive 60 mths postop |
| Postrzech-Adamczyk et al. [21] | 2 | Persistent cough, exertional dyspnoea | A heterogeneous solid cystic 6 cm mass in RUL with mediastinal LN enlargement | Adjuvant chemotherapy | Died 6 mths after diagnosis |
| Right sided hemiparesis | A homogenous high density large round 5 cm mass in LUL surrounded with ground-glass opacity. | Palliative treatment | Died 3 mths after diagnosis | ||
| Zhang et al. [22] | 1 | Asymptomatic | An irregular homogenous high density 4 cm mass in LLL | Pneumonectomy + Adjuvant chemotherapy | Alive 18 mths postop |
| Agarwal et al. [23] | 1 | Anorexia, weight loss, progressive dyspnoea, chest pain, back pain, abdominal distention | Circumferential thickening of pleura on left with its extension as a heterogenous lobulated mass, collapse of left lung and pleural effusion | None | Died 25 days after admission |
| Baniak et al. [24] | 1 | Weakness, chest pain, nausea, back pain | pleural based heterogenous nodular mass in LLL with effusion | Immunomodulators | Died 4 mths after diagnosis |
| Feng et al. [25] | 1 | Dry cough, hemoptysis, dyspnoea | Discrete bilateral consolidations with a 3 × 2 cm nodule in RUL and a 3 × 4 cm subpleural homogenous mass with slightly uneven enhancement in LLL accompanied with surrounding bilateral paving pattern | None | Died 2 mths after diagnosis |
| Kim et al. [26] | 1 | Productive cough | A multi-lobulated 5 × 3.4 cm mass with homogeneous enhancement (28 HU) in RUL | None | Died 3 mths after diagnosis |
| Kyriakopoulos et al. [27] | 1 | Headache, nausea, ataxic gait | A heterogeneous ill defined mass in RUL with hilar LN enlargement | Radiotherapy + biochemotherapy | Died 5 mths after diagnosis |
| Yamamoto et al. [28] | 1 | Asymptomatic | A homogenous well-defined 13 mm nodule in LLL | Lobectomy + chemo immunotherapy | Died 15 mths post op |
| Present case, 2017 | 1 | Productive cough, back pain | A large irregular heterogeneous 6.9 × 6.5 cm mass in LUL and irregular solid 4.3 × 3.6 cm mass in RLL with pleural effusion | Chemotherapy | Died 1 mth after diagnosis |
LLL: Left Lower Lobe; LUL: Left Upper Lobe; RLL: Right Lower Lobe; RML: Right Middle Lobe; RUL: Right Upper Lobe; LN: Lymph Nodes; GIT: Gastrointestinal Tract; mths: Months; yrs: Years.
Table 1: Cases of primary pulmonary malignant melanomas reported in the literature.
Clinical presentation of PMM
Clinical presentation (Table 1) of PMM lacked specificity with patients presenting with pulmonary and/or extrapulmonary symptoms. Ten of the cases were asymptomatic and were incidental findings in routine examination. The pulmonary symptom was a persistent cough (10 of the 28 patients), progressive dyspnea (8 of the 28 patients), chest pain (4 of the 28 patients), sputum production (3 of the 28 patients), and hemoptysis (2 of the 28 patients). The extrapulmonary symptoms included significant weight loss (5 of the 28 patients), fatigue (3 of the 28 patients), anorexia (3 of the 28 patients), back pain, headache, neck pain, shoulder pain, nausea and hemiparesis. However, these symptoms were not common and depended on the site of metastasis.
Chest imaging
In chest radiography, all patients had a mass or opacity, some had infiltrates, multiple nodules, atelectasis, pleural effusion. In chest computed tomography (Table 1), according to literatures, primary pulmonary melanoma was distributed in bilateral upper lobe and lower lobe lungs, predominantly in the left lower lobe; usually solitary (19 out of 28 patients) solid nodules or masses, lobulated (17 out of 28), with homogenous density (20 out of 28). Some were accompanied by central necrosis, consolidation, ground glass opacity, crazy paving pattern, collapse of lung lobe, pleural thickening and pleural effusion, mediastinal lymphadenopathy. The imaging findings lacked specificity.
Treatment and prognosis
Lobectomy or pneumonectomy with lymph node dissection is the mainstay of treatment in patients diagnosed with primary pulmonary malignant melanoma. Adjuvant therapy has not been done in a randomized fashion due to the rarity of the disease. Surgical resection was the primary treatment (14 of the 28 reported patients) while adjuvant systemic treatment was delivered just to 9 patients (Table 1). In addition, palliative radiotherapy to distant sites had been administered in 3 patients (Table 1). In general, it seems that most patients (15 of the 28 patients) were diagnosed with metastatic disease. The sites of metastatic involvement included the contralateral lung, liver, brain, bones, and pericardium. The prognosis (Table 1) was very poor and the majority (19 of 28 patients) survived less than 18 months.
Melanoma is a malignant neoplasm of melanocytes which usually occurs on the skin but may occur in other primary sites, such as oral cavity, paranasal sinuses, larynx, esophagus, liver, vagina, cervix and anorectal regions [1]. When we encounter pulmonary masses, clinically diagnosis of primary pulmonary MM is rarely taken into consideration, as primary PMM is very rare. Additionally, there aren't specific radiologic features for pulmonary MM [26]. The gold standard for the diagnosis of pulmonary MM is the histological features. Approximately 5-10% of patients with metastatic melanoma have a primary melanoma of unknown origin [26]. Thus, meticulous systemic assessment of the whole body is to be done [2].
The diagnosis of primary PMM is based on clinical and pathological criteria [26]. The clinical criteria include the presence of a solitary lung mass or nodule, histopathology diagnosis confirmed by immunohistochemistry and/or electron microscopy, absence of history suggestive of a previous melanoma, and no demonstrable melanoma outside the thorax at the time of diagnosis [27]. So, our case also fulfils these criteria and can be diagnosed as primary PMM.
Radiologic features are ingenious to narrow down the differential diagnosis. But many studies have not stated the detailed imaging findings in their case reports. In CT scan, PMM presents as a well demarcated round or lobulated solitary nodule or mass with heterogeneous enhancement, and with or without mediastinal lymph nodes enlargements [25]. Our case revealed the nodules or masses had higher CT value (mean CT value of 67 HU in mediastinum window) with mild enhancement in the chest CT. The metastatic nodules also had higher CT value. MM is composed melanocytes, rich with melanin granules, which would cause the higher CT value than other tumor [26]. But almost none of the literature has described it. This imaging finding may be a specific parameter to form a differential diagnosis of MM. Furthermore, MRI examination provides more detailed information in primary PMM. On MRI, melanotic and amelanotic patterns of malignant melanoma are seen. A melanotic pattern shows hyper-intensity on T1WI and hypo-intensity on T2WI, while an amelanotic pattern shows hypo-intensity or iso-intensity on T1WI and hyper-intensity or iso-intensity on T2WI [29,30]. So, MRI is the best diagnostic method for detecting brain metastases of MM [26]. Likewise, in our case, the MR images of the metastatic lesions were hyper-intense on T1WI and hypo-intense on T2WI. Recent reports suggest that FDG-PET/CT can efficiently detect micrometastatic lesions of MM, that could not be seen in CT scan and aid in restaging and management of recurred MM [26]. But, there is few information on this matter.
In histology, primary PMM resembles skin or mucosa and metastatic melanoma [3,7,9]. The tumor is composed of nesting of epithelioid cells, or spindle cells arranged in fascicles, with or without melanin granule deposition. The immunohistochemical markers are pathognomonic to distinguish a primary MM from a metastatic one. In melanoma, S-100, HMB-45, vimentin, (pan-CK, CK7, CK20, EMA), keratin, P63, TTF-1, CD45, are positive and muscular markers (actin and desmin) are negative [31]. S-100 and HMB-45 markers expression is decreased in metastatic melanomas [26,31]. In our patient, HMB-45, S-100, Melan-A and VIMENTIN were positive aiding to the confirmation of the diagnosis. Therefore, final diagnosis of a primary pulmonary MM of the lung is based upon combined clinical, radiological, histological findings and immunehistochemical staining analysis [5].
As for the treatment, patients diagnosed with primary pulmonary malignant melanoma should undergo lobectomy or pneumonectomy with lymph node dissection [1,9]. At the time of diagnosis of the primary tumor, most patients with mucosal melanoma will have metastases. However, adjuvant therapy has not been studied in a randomized fashion because of the rarity of the disease. The role of chemotherapy is not fully clarified. Bio-chemotherapy, combination of chemotherapy and immunotherapy, is an acceptable choice for aggressive bulky disease always after taking into consideration patients’ performance status and comorbidities, and the relatively expanded toxicity profile of the combination therapy [27]. Palliative radiation therapy is utilized when bulky metastatic disease is present [27]. Due to the rarity of primary pulmonary malignant melanomas, randomized trials for assessing different treatment modalities are demanding.
In conclusion, we presented a case of pulmonary malignant melanoma with metastasis and had a poor prognosis, and summarized the key aspects of this rare disease based on the available published literatures. We suggest, when encountered with homogenous nodules or masses with higher CT value in lung and metastases, and on MRI hyper-intensity on T1WI and hypo-intensity on T2WI, with the exception of hemorrhage, PMM should be taken into consideration as a differential diagnosis.
