Shoulder Dislocation with Head and Shaft Fracture Ipsilateral

Journal of Arthritis

ISSN - 2167-7921

Case Report - (2016) Volume 5, Issue 2

Shoulder Dislocation with Head and Shaft Fracture Ipsilateral

Tomás Pérez Cervera*, Luis Roca and Miguel Ángel Martín Montalvo
Hospital Universitario Virgen Macarena Sevilla, Spain
*Corresponding Author: Tomás Pérez Cervera, Hospital Universitario Virgen Macarena, Ciurgía Ortopédica y Traumatología, Sevilla 41018, Spain, Tel: +34660276344 Email:

Abstract

Accompanied shoulder dislocation of the proximal humerus fracture associated with ipsilateral shaft fracture is a rare injury described in literature collection and whose treatment protocol is not clearly established. Here we present the case of 63 years old male who suffered a fall after slipping in a pool and presented a humeral shaft fracture associated with ipsilateral anterior glenohumeral dislocation and fracture of the proximal humerus in three fragments with involvement of the anatomical neck. The patient underwent a closed reduction first attempt with the help of two needle percutaneous. Axillary artery was injured so had to undergo a second time for another intervention in which we made open reduction and osteosynthesis by proximal humerus long plate and hemiarthroplasty.

Keywords: Shoulder dislocation with shaft fracture; Humeral shaft fractures with dislocation; Proximal humerus fracture and shaft fracture

Introduction

Anterior glenohumeral dislocation associated with ipsilateral shaft fracture is a rare injury. The first case in modern literature was described in 1940 by Winderman. Since then, 24 new cases have been described by others (Table 1) [1].

Author/Dot dapOsna Madbanias Ditdorodon MIMI linarmeo 114slotadaa Th Press TY Anlb
Ilmit.3)04 Me F Pal Animate 3 gun Md./3 Owed Ceoptanim SSW Good
lnattrainel :111 conerrer belt Anterior. CIF M4/3 Closed ()RIF Dynamic Coadermoon Fit Good
howthlare206 In 31 MCC Amain htsa/3 Chord Reddns&lawnersedullan Nat (Mod
4 Ism/ litnl IS M MCC Armand Miblesill (bird Dynamic Good
            Corapremion Fide and Scream
  :OM MCC Antrnar Ian Ituttertb timed IMF Dynamic Conan-dim nor Rota n rakey
Mafia/1996 19M MST Ant, ...( t. i: Maiand/ 3 Itrandly timed Druids InvAbl
            Compredost lido DI 13drg, Ore nrsi IR 10
Caladoor/1106 7711 MW Ammar Slid/3 aimed Dynamic Comanweion liar lbatial n Paley.
              riwohrd
Daekt/ 1995 29 U MCC Animist lbath/3 Closed Stsba/Brace CS7 *sopa. nesolord
  67 11 WIC Minim M/3 Owed latnamord. Rod lambed aid. litic wad IX
KontakiV10111 II 14 /417C Anterior 114/3 Opts   Mr Si. aid. and ER 10
            Hale and Screwy dee
  4131 Fa tom 201 Antedate 16113 Clad 1T-Slab (SAN) the FR to dew
Commilld4 1611 MCC Anardoe Mid./3 Chord 3 tin stahaanbai .r 1 la Lethal bxlmlemw (Dyed
Stephens. Kotty/lleol 29 31 MW Amnion GTV M4/3 Closed it/ limb Lenge:dab* APPrIttwt to Amid Clewed Itedurnew Edema 11A Elation lbw Abd M dna
lb:1pm/ ttes3 2.511 Operating Maidnery 0 Tracduad Animist. GIP Mal Loy/ 3 hand* Gamed 501111 Good
  C V MW Antsdne limn nomad w/ Sielawada SWIM Good
          pin
Bake/1971 25 !I Oweratint Mad/marry Antral*. G17 Mid/3 ORO latranedsdbryRaab 74 km. MA malmetat
    efalb       OW
Gu1/19S7• n/a n/a &ardor Finsil n/a a/a a/a
110bn/1911 a/a n/a n/a n/a st/o n/a a/a
Windermid/ HMO 614 F bll Submwaroid Mi1/3 Owed math On Split Gaol M0690. Dimbred a karate
          Oo avid
Mth/1919 '1711 Fall dome stars Submaratold Proa/3 Closed SPIN roll 11011. time rwrw­Dt^LIfo;fl'U!a
•ubuietd atom Ranson 111K1/

Table 1: This table mimes the trimeted powlsosd bumf we Inctursw1okrations Mai awcanded hewn trastsrms Owls trmaarat aid antra.

These injuries often occur as a result of high energy trauma. The literature concerning this rare lesion is limited to “case reports”, within which there are different treatments applied [2].

The purpose why we report this case it is to show the different options of treatment for an unusual injury which was treated with hemiarthroplasty with plate screws fixation of shaft.

Case History

The patient was a 63 year old male slipped in a pool and fell on his right arm. On arrival to the emergency room right arm and shoulder were sore, swollen and deformed.

Clinical examination showed right shoulder deformity to the middle third diaphyseal with no neurovascular abnormalities. Also anterior displacement of the head and a positive sulcus sign was found.

Radiographs showed a spiral fracture of the humeral shaft with lateral angulation, three parts anatomic neck fracture and anterior glenohumeral dislocation (Figures 1 and 2).

arthritis-fracture-dislocation

Figure 1: Rx shows fracture – dislocation with ipsilateral shaft fracture.

arthritis-neck-fracture

Figure 2: Rx shows fracture in three parts with anatomical neck fracture.

Firstly, in the operating room, under general anesthesia closed reduction of anterior dislocation using two percutaneous pinning was attempted but it was impossible to reduce it [3]. When we removed the needles, bleeding is observed by one of the inlets of the needles which refers to maintaining compression.

Weak radial pulse was palpable without uptake in the O2 sensor so vascular injury was suspected and Hemodynamic Vascular Surgeon was informed.

Vascular surgeons confirmed a small tear at the level of the axillary artery which was sutured. This complication forced us to delay the final intervention for about five days.

Secondly, under new general anesthesia, new closed reduction was attempted without success.

Thus, using extended deltopectoral approach we were able to obtain the reduction of the humeral head, though not without difficulties.

Once the fracture is reduced, we noted the existence of a proximal humerus fracture in 3 fragments with involvement of the anatomical neck and spiral fracture of the shaft.

Due to increased risk of necrosis of the humeral head, we consider the optimal treatment was the placement of a cemented humeral hemiarthroplasty (Equinoxe, Exactech©) combined with a dynamic long compression plate for proximal humerus (Periloc. Smith and Nephew©) and three cerclages Dall-Miles (Figures 3 and 4).

arthritis-hemiarthroplasty-during

Figure 3: DLCP and hemiarthroplasty during their collocation.

arthritis-hemiarthroplasty-cerclages

Figure 4: DLCP with hemiarthroplasty and cerclages.

Layered closure was performed with a suction drain wich was removed in 24 hours. The radiological result is shown in Figures 5 and 6.

arthritis-Postsurgery-Rx

Figure 5: Postsurgery Rx.

arthritis-Radiological-result

Figure 6: Radiological result.

Discussion

In the current literature there is not any case of humeral shaft fracture combined with fracture - dislocation of the humeral head affecting the ipsilateral and anatomical neck. Since 1940 only 24 cases of fractures-dislocations of the humeral head with ipsilateral shaft fractures have been described (Table 1) [1]. Five of them described greater tuberosity fracture. One article described a proximal humerus fracture in three fragments, but without involvement of the anatomical neck, hence the uniqueness of our case. The majority of reported cases has occurred as a result of high energy trauma, unlike ours that was for a simple accidental fall after slipping on a wet floor [4,5].

In previous publications, the injuries were caused by traffic accidents involving motorcycles or cars, precipitation from two or more meters high or even workplace machinery accidents.

We must emphasize the mechanism of injury. Case reports in the literature have advocated two possible mechanisms of injury. Sankaran- Kutty and Sadat-Ali [6] suggested that the force exerted along the axis of the humerus simultaneously fractured the humerus and dislocated the shoulder, whereas Kontakis et al. [7,8] proposed that the shoulder dislocated first and subsequent, bending or torsion forces fractured the shaft of humerus. We believe that the mechanism of injury in our patient was as described in the second case, and this is supported by the fracture pattern that is spiral and acute bending of the arm during emergency presentation.

In a prospective study developed by Court - Brown showed that 49% of proximal humerus fractures were classified as Neer Type I. 28% was classified as broken into two fragments of the surgical neck and only 9% as fractures into three fragments with greater tuberosity and fitness for repair broken neck. Our patient was classified as a fracture in three fragments with the peculiarity of the anatomical neck fracture.

The humeral head receives vascular supply through the anterior circumflex artery and to a lesser extent is also nourished by vessels entering through the posteromedial region of the proximal humerus, and metaphyseal vessels of the tuberosity. Doppler confirmed that if the humeral head fragments include at least 8 mm medial calcar, avascular necrosis risk drops significantly due to the blood pool present there. It also determined that avascular necrosis was ahead in 97% of cases if they had an anatomical neck fracture, small medial calcar and periosteal disruption of the medial line.

Our patient had a fracture of the anatomical neck, so he had a high risk of avascular necrosis to which must be added the time elapsed since the injury until surgery.

Fractures in three fragments of the proximal humerus with dislocations associated with ipsilateral humeral shaft fractures are rare. The closed each of these lesions is suitably reduced, if it is possible to do in emergencies, which will preserve blood flow to the fracture fragments.

The second important aspect of our case is its management. Literature reflects that hemiartroplasty may be a viable option for complex fractures of the proximal humerus with even better results than open reduction and fixation [9]. The treatment modalities include closed reduction and plaster of paris slab application, nailing and plating of the humeral shaft along with reduction of the shoulder dislocation. Good clinical results have been reported with almost all the modalities. However, there is no consensus in the literature for treating this type of injury [10-12]. In fact, we did a combination of several options to overcome the difficulties we were facing for the internal fixation of the fracture and for the viability of the humeral head.

The last aspect of this case is its outcome. Almost all reported cases have reported satisfactory outcome (some degree of restriction of abduction and flexion) despite different modalities of management. We also had a good outcome in our patient despite having a more severe injury.
